General |
|
| Dimension | 6.2 x 2.6 x 3.7 (158 x 66 x 95 mm) |
|---|---|
| Weight |
1.9 lbs (862 g) |
| Water rating | IPX7 |
| Display Size | 1.2″ (32 mm) diagonal |
| Battery Type | 2 AAA lithium batteries (included) |
| Battery life |
up to 1 year |
| Multi-color display | |
| Operating range | -20° C to 60° C (-4° F to 140° F) |
| Interface | microUSB™ |
| Laser classification | Class 1 |
Sensors |
|
| GPS | |
|---|---|
| Compass | |
Scope Features |
|
| Colored pins | yes (multiple) |
|---|---|
| Ranging distance | 250game_500target |
| Magnification | 3.5x |
| Field of view | 5 degrees |
| Eye relief | 2.4″ (62 mm) |
| Focus adjustment | +/- 2 diopters |
| Pin brightness | ambient light sensor controlled or manual |
| Shot counter | |
| Laser Locate™ feature | |
| Multiple arrow profiles | |
| Compatible with Garmin GPS devices | |
| Auto calibration | |
| AutoCal | Bow speeds up to 650 FPS, out to 80 yds (73 m) |
| Electronic level | |
| Angle compensated distance | |
| Aiming accuracy | 1/2 MOA (1/2″ at 100 yds) |
| Flight apex | |
| Auto brightness | |
| Steady aim | |
| Configurable aim point shapes | |
| Dual rangefinder triggers | |
| Integrated mount | |
| Roll at shot | |
| Impulse duration | |
Daily Smart Features |
|
| Connectivity | ANT® |
|---|---|
