- Campagnolo Body, suitable for 9- to 12-speed Campagnolo cassette
- SRAM XD Body, suitable for 11- to 12-speed SRAM XD-R cassettes
- SHIMANO Micro Spline, suitable for all SHIMANO Micro Spline cassettes
Need help installing your freehub body? Check out this video:
Fitting the Freehub Body
2. Check Axle
Tacx NEO 2T Smart includes the following axles suitable for bikes with:
- Direct drive quick release axle (130 mm/135 mm x 5 mm)
- Thru-axle end caps (142 x 12 mm and 148 x 12 mm) for bikes with thru-axle
For bike dimensions outside of the industry standard, Garmin offers this adapter set as an additional accessory:
Direct Drive Quick Release with Adapter Set [10 x 135 Non-drive Side (NDS), 12 x 135 NDS and 10 x 135 Drive-side (DS)]
Need help installing your axle? Check out these videos:
Fitting Bike with Quick Release
Fitting Bike with Thru-Axle
3. Cassette
The Tacx NEO 2T Smart trainer doesn't include a cassette. You will need a cassette of the same type and speed as the bike you plan to use with the trainer. Please visit your local bike shop, or search online to find the right cassette for your bike.
Maps for New Regions
Need maps for regions other than the ones that came on your device? See all maps that are compatible with your device.
Need a map update?
Update the maps that came with your device for the best navigation experience.
Check for Updates
General |
|
| Dimension | 22.6″ x 29.5″ (575 x 750 mm) |
|---|---|
| Height | 21.7″ (55 cm) |
| Weight |
47.4 lbs (21.5 kg) |
| Accuracy (+/-) | <1% |
Connectivity |
|
| Wireless communication | ANT+ connectivity, BLUETOOTH wireless technology |
|---|---|
| Control by |
Smartphone, tablet, ANT+ bike computers, stand alone, computer connection via ANT+ antenna |
| Read out on |
Smartphone, tablet, bike computer, computer with ANT+ antenna |
| Connection indicator (ANT+/Bluetooth) | 2 LEDs |
| Power indicator | Multicolor LED, spot on floor |
Indoor Training Features |
|
| Magnets | 32 neodymium magnets |
|---|---|
| Electrical requirement | 110-240 Volts |
| Suitable cassettes |
Shimano/SRAM 9 to 11 speed compatible Campagnolo (compatible, requires special cassette body) SRAM 12 speed/XDR (compatible, requires special cassette body) Shimano 12-speed Hyperglide+ Shimano Micro Spline |
| Suitable axles |
Direct Drive quick release axle (130 mm/135 mm X 5 mm) for bikes with quick release axle Thru axle end caps (142 mm/148 mm X 12 mm) for bikes with thru-axle For bike dimensions outside of the industry standard, Garmin offers this adapter set as an additional accessory: 135 mm Thru-Axle Adapter Set [10 x 135 Non-drive Side (NDS), 12 x 135 NDS and 10 x 135 Drive-side (DS)]. |
| Max power | 2200 Watt |
| Max incline | 25% |
| Simulation of descent | |
| Max torque | 88 Nm |
| Max brake force | 260 N |
| Flywheel | Virtual |
| Mass inertia | Variable to 275.6 lbs (125 kg) |
| Calibration | No calibration needed |
| Output | Speed, cadence, power |
| Measured Speed | |
| Measured Cadence | |
| Measured Power | |
| Works without mains connection | |
| Drivetrain Options | SHIMANO/SRAM 9-11, SRAM XD/XD-R, SHIMANO Micro Spline, Campagnolo 9-12, Campagnolo N3W, Zwift Cog and Click |
|---|
