Name: JL Audio® M3 Marine Speakers
Brand: Garmin Official Site
SKU: 010-03266-00
Price: 78 USD
Availability: InStock

JL Audio® M3 Marine Speakers

M3 marine speakers are designed to produce a powerful, smooth sound with amazing fidelity, 2 sizes and 5 styles, and models with built-in RGB LED Lighting.

Guaranteed Safe Checkout

General

Sizes 7.7″ Color White Classic, White Sport or Gray Sport Physical dimensions (Diameter) 7.70″ (196 mm) Physical dimensions (Depth) 7.7″ (Classic): 12.62″ (321 mm)
7.7″ (Sport): 12.69″ (323 mm) Speaker type Enclosed Coaxial Continuous power handling (RMS) 70 W Sensitivity (SPL @ 1 W/1 m) 90.5 dB Frequency response (+/- 3 dB) 55 Hz-25 kHz Nominal impedance 4 Ω Recommended amplifier power (RMS) 20-140 W/Channel LED lighting yes – RGB (selected Sport models only) LED supply voltage 10-14.4 VDC LED Load Current @ 14.4 VDC (max) 108 mA Cone material Injection-molded, mica-filled polypropylene Tweeter type Silk Dome Tweeter size 0.75″ (19 mm) Warranty 3 years

Connections
Speaker connections	Flying Lead with 16 AWG wire (10 ft)
LED connection	Flying Lead with 4-conductor 20 AWG wire (selected Sport models only, 10 ft)

Additional

The enclosure recommendations listed above are external dimensions which assume the use of 0.75″>” (19 mm) thick material. If you are using 0.625″>” (16 mm) thick material, subtract 0.25″>” (6.5 mm) from each dimension. Do not use any material with a thickness of less than 0.625″>” (16 mm) as this may compromise the rigidity of the enclosure. All enclosure volumes listed above are net internal volumes! Driver displacement, port displacement and brace displacement must be added to obtain the final gross internal volume. All enclosure dimensions above have already taken this into account. When using multiples in a common enclosure you will need to recalculate the enclosure and port dimensions. For assistance please contact your authorized JL Audio dealer or JL Audio Technical Support. We recommend the use of this in a bi-amplified system using high-quality satellites and a high-quality amplifier. We do not recommend the use of this with a passive crossover (coil), as this type of device will adversely affect performance.
