Physical & Performance
- Electrical: 14 or 28 VDC aircraft power
- Unit size: 3.4″>”W x 3.6″>”H x 3.0″>”D (86.4 x 91.4 x 76.2 mm)
- Weight: 13.3 oz (377.0 g) unit
- Display size: 3.5″>” diagonal (88.9 mm diagonal)
- Display resolution: 320 x 240 pixels (QVGA), LED backlit color LCD
- Receiver: High-sensitivity GPS
- Maximum indicated airspeed: 300 kts
- Altitude range: -1,400 – +30,000 ft
- Vertical speed range: ± 20,000 ft/minute
- Pitch/roll range: ±360°
- Backup battery (optional): Rechargeable lithium-ion
- Battery life: Up to 4 hours
