General
Dimension
2.7 x 6.4 x 1.3” (6.8 x 16.2 x 3.4 cm) *dimensions do not include antenna
Weight
9.9 oz (280 g) with standard antenna and battery
Water rating
IPX7
Touchscreen
Display Type
transflective, color TFT touchscreen
Display Size
(WxH) 4.7 cm x 7.7 cm, 3.5″ diag (88.9 mm)
Display resolution
282 x 470 pixels
Battery Type
rechargeable lithium-ion (included)
Battery life
up to 55 hours
Memory/History
16 GB
Interface
high-speed USB-C
Maps & Memory
Preloaded maps
yes (TOPOActive)
Ability to add maps
yes (see Additional)
Automatic routing (turn by turn routing on roads) for outdoor activities
Yes (with optional mapping for detailed roads)
Satellite Imagery
yes (direct to device; no annual subscription required)
External memory storage
microSD card (not included)
Waypoints/favorites/locations
10,000
Tracks
up to 20 assets (any combination of compatible dog devices and handhelds)
Navigation Track Log
20,000 points, 250 saved spx tracks, 300 saved fit activities
Navigation Routes
250
Stored contacts
250 dogs
Group management
Sensors
GPS
Galileo
Barometric altimeter
Compass
Yes (tilt-compensated 3-axis)
High-sensitivity receiver
Safety and Tracking Features
LiveTrack
Tactical Features
XERO™ Locations
Outdoor Recreation
Point-to-point navigation
Area calculation
Fish forecast
Sun and moon information
Custom maps compatible
Radio Features
Frequency band
MURS
Channels
5
Range
9 miles with compatible dog devices
Location reporting (send and receive GPS positions)
Vibration alert
Contacts
Outdoor Applications
Compatible with Garmin Explore™ app
Garmin Explore website compatible
Dog tracking
Connections
Connections Wireless Connectivity
yes (Wi-Fi® , BLUETOOTH® Low Energy and ANT+® )
Additional
Additional
Ability to add maps: yes (Outdoor Maps+)
